轴承代号 | 外型尺寸 | 重量 | 额定负荷 | |||||||
(mm) | (KG) | (KN) | ||||||||
d | D | T | B | C | rmin | r1min | Weight | 动负荷 | 静负荷 | |
LM12749/10 | 21.987 | 45.237 | 15.494 | 16.637 | 12.067 | 1.3 | 1.3 | 0.116 | 26.6 | 30 |
LM11949/10 | 19.05 | 45.327 | 15.494 | 16.637 | 12.065 | 1.3 | 1.3 | 0.12 | 28.3 | 28.6 |
L45449/10 | 29 | 50.292 | 14.224 | 14.732 | 10.668 | 3.5 | 1.3 | 0.113 | 28 | 35.5 |
LM12649/10 | 21.43 | 50.005 | 17.526 | 18.288 | 13.97 | 1.3 | 1.3 | 0.168 | 34.2 | 35 |
LM12749/10 | 21.987 | 45.237 | 15.494 | 16.637 | 12.067 | 1.3 | 1.3 | 0.116 | 26.6 | 30 |
LM102949/10 | 45.242 | 73.431 | 19.558 | 19.812 | 15.748 | 4 | 1 | 0.308 | 51.4 | 79 |
LM501349/10 | 41.275 | 73.431 | 19.558 | 19.812 | 14.732 | 3.5 | 0.8 | 0.329 | 50.4 | 62.5 |
L44643/10 | 25.4 | 50.292 | 14.224 | 14.732 | 10.668 | 1.3 | 1.3 | 0.126 | 27 | 32 |
L44649/10 | 26.988 | 50.292 | 14.224 | 14.732 | 10668 | 3.5 | 1.3 | 0.119 | 27 | 32 |
L68149/10 | 35 | 59.131 | 15.875 | 16.764 | 11.938 | - | 1.3 | 0.172 | 36 | 48 |
45284/45220 | 50.8 | 104.775 | 30.162 | 30.958 | 23.812 | 6.4 | 3.3 | 1.115 | 130 | 169 |
47874/47420 | 69.85 | 120 | 32.545 | 32.545 | 26.195 | 3.5 | 3.3 | 1.45 | 147 | 214 |
LM48548/LM48510 | 34.925 | 65.088 | 18.034 | 18.288 | 13.97 | 4.9 | 1.3 | 0.246 | 46.5 | 56 |
LM48548/LM48511A | 34.925 | 65.088 | 21.082 | 18.288 | 17.018 | 4.9 | 1.5 | 0.273 | 42.5 | 51 |
LM48548A/LM48511A | 34.925 | 65.088 | 21.082 | 18.288 | 17.018 | 0.8 | 1.5 | 0.273 | 42.5 | 51 |
53176/53375 | 44.45 | 95.25 | 30.958 | 28.3 | 20.638 | 1.3 | 0.8 | 0.927 | 82.5 | 92 |
53178/53375 | 44.45 | 95.25 | 30.958 | 28.3 | 20.638 | 2 | 0.8 | 0.927 | 82.5 | 92 |
55176/55443 | 44.45 | 112.712 | 30.162 | 26.909 | 20.638 | 0.8 | 3.3 | 1.421 | 93.1 | 140 |
55187/55443 | 47.625 | 112.712 | 30.162 | 26.909 | 20.638 | 3.5 | 3.3 | 1.371 | 93.1 | 140 |
LM67048/LM67010 | 31.75 | 59.131 | 15.875 | 16.764 | 11.811 | 5 | 1.3 | 0.176 | 31.5 | 36 |
M86649/M86610 | 30.162 | 64.292 | 21.433 | 21.433 | 16.67 | 1.5 | 1.5 | 0.338 | 47 | 56 |
HN88649/HM88610 | 34.925 | 72.233 | 25.4 | 25.4 | 19.842 | 2.3 | 2.3 | 0.491 | 58.3 | 69 |
JLM104948/JLM104910 | 50 | 82 | 21.501 | 21.501 | 17 | 3 | 0.5 | 0.419 | 69.5 | 94 |
LM104949/LM104911 | 50.8 | 82.55 | 21.59 | 22.225 | 16.51 | 3.5 | 1.3 | 0.414 | 69.5 | 94 |
LM501349/LM501314 | 41.275 | 73.431 | 21.43 | 19.812 | 16.604 | 3.5 | 0.8 | 0.335 | 56 | 69.5 |
LM501349/LM501310 | 41.275 | 73.431 | 19.558 | 19.812 | 14.732 | 3.5 | 0.8 | 0.323 | 56 | 69.5 |
LM603049/LM603012 | 45.242 | 77.788 | 21.43 | 19.842 | 16.667 | 3.5 | 0.8 | 0.377 | 57.5 | 73.5 |
LM603049/LM603014 | 45.242 | 80 | 19.842 | 19.842 | 15.08 | 3.5 | 0.8 | 0.394 | 57.5 | 73.5 |
M802048/M802011 | 41.275 | 82.55 | 26.543 | 25.654 | 20.193 | 3.5 | 3.3 | 0.623 | 80.5 | 104 |
15113/15245 | 31.75 | 62 | 19.05 | 20638 | 14.288 | 0.8 | 1.3 | 0.255 | 46.5 | 54 |
18590/18520 | 41.275 | 73.025 | 16.667 | 17.462 | 12.7 | 3.5 | 1.3 | 0.279 | 46 | 55.5 |
24780/24721 | 41.275 | 76.2 | 22.225 | 23.02 | 20.638 | 3.5 | 1.5 | 0.456 | 58.3 | 67 |
25572/25520 | 38.1 | 82.931 | 25.4 | 25.4 | 19.05 | 0.8 | 0.8 | 0.64 | 76 | 98 |
25577/25520 | 42.875 | 82.931 | 23.812 | 25.4 | 19.05 | 3.5 | 0.8 | 0.562 | 76 | 98 |
25580/25520 | 44.45 | 82.931 | 23.812 | 25.4 | 19.05 | 3.5 | 0.8 | 0.558 | 76 | 98 |
25590/25520 | 45.618 | 82.931 | 23.812 | 25.4 | 19.05 | 3.5 | 0.8 | 0.542 | 76 | 98 |
25877/25821 | 34.925 | 73.025 | 23.812 | 24.608 | 19.05 | 3.5 | 0.8 | 0.461 | 71 | 85 |
29590/29522 | 66.675 | 107.95 | 25.4 | 25.4 | 19.05 | 3.5 | 0.8 | 0.869 | 91.5 | 140 |
29685/29620 | 73.025 | 112.712 | 25.4 | 25.4 | 19.05 | 3.5 | 3.3 | 0.863 | 85.8 | 91.1 |
LM29749/LM29710 | 38.1 | 65.088 | 18.034 | 18.288 | 13.97 | 2.3 | 1.3 | 0.238 | 43.5 | 57 |
LM29749/LM29711 | 38.1 | 65.088 | 19.812 | 18.288 | 15.748 | 2.3 | 1.3 | 0.251 | 43.5 | 57 |
33225/33472 | 57.15 | 120 | 29.794 | 30.162 | 23.444 | 3.5 | 0.8 | 1.637 | 105 | 131 |
33262/33462 | 66.675 | 117.475 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 1.32 | 107 | 139 |
33275/33462 | 69.85 | 117.475 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 1.261 | 117 | 175 |
33281/13462 | 71.438 | 117.475 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 1.2 | 117 | 175 |
33885/33821 | 44.45 | 92.25 | 27.783 | 28.575 | 22.225 | 0.8 | 2.3 | 0.95 | 107 | 139 |
33891/33821 | 52.388 | 95.25 | 27.783 | 28.575 | 223.225 | 3.5 | 2.3 | 0.816 | 107 | 139 |
33889/33821 | 50.8 | 95.25 | 27.783 | 28.575 | 22.225 | 3.5 | 2.3 | 0.845 | 107 | 139 |
39585/39520 | 63.5 | 112.712 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 1.24 | 138 | 195 |
39590/39520 | 66.675 | 112.712 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 1.164 | 138 | 195 |
02474/02420 | 28.575 | 68.262 | 22.225 | 22.225 | 17.462 | 0.8 | 1.5 | 0.048 | 57 | 67 |
02872/02820 | 28.575 | 73.025 | 22.225 | 22.225 | 17.463 | 0.8 | 3.3 | 0.484 | 56.5 | 68 |
14124/14276 | 31.75 | 69.012 | 19.845 | 19.583 | 15.857 | 0.8 | 1.3 | 0.347 | 43.1 | 35.8 |
14313/14276 | 33.338 | 69.012 | 19.845 | 19.583 | 15.857 | 0.8 | 0.3 | 0.333 | 48.5 | 58 |
14137/14276 | 34.925 | 39.012 | 19.845 | 19.583 | 15.857 | 1.5 | 1.3 | 0.314 | 44 | 55 |
14138A/14276 | 34.925 | 69.012 | 19.845 | 19.583 | 15.857 | 3.5 | 1.3 | 0.312 | 48.5 | 58 |
15100/15245 | 25.4 | 62 | 19.05 | 20.638 | 14.288 | 0.8 | 1.3 | 0.33 | 46.5 | 54 |
15106/15250X | 26.988 | 63.5 | 20.638 | 20.638 | 15.875 | 0.8 | 1.58 | 0.31 | 41.7 | 52 |
539/532A | 53.975 | 111.125 | 38.1 | 36.957 | 30.162 | 2.5 | 2.3 | 1.58 | 141 | 177 |
539/532 | 53.975 | 111.125 | 38.1 | 36.957 | 33.338 | 3.5 | 3.3 | 1.66 | 141 | 177 |
1988/1931 | 28.575 | 60.325 | 19.845 | 19.355 | 15.875 | 3.5 | 1.3 | 0.25 | 37 | 46 |
28584/28521 | 52.388 | 92.075 | 24.608 | 25.4 | 19.845 | 3.6 | 0.8 | 0.66 | 83.5 | 116 |
2780/2720 | 36.487 | 76.2 | 23.812 | 25.654 | 19.05 | 1.5 | 3.3 | 0.513 | 67 | 85 |
2785/2720 | 33.338 | 76.2 | 23.812 | 25.654 | 19.05 | 3.5 | 3.3 | 0.551 | 73 | 90.5 |
2788/2720 | 38.1 | 76.2 | 23.812 | 25.654 | 19.05 | 3.5 | 3.3 | 0.494 | 73 | 90.5 |
2789/2729 | 39.688 | 76.2 | 23.812 | 25.654 | 19.05 | 3.5 | 0.8 | 0.475 | 73 | 90.5 |
2790/2720 | 33.338 | 76.2 | 23.812 | 25.654 | 19.05 | 1.5 | 3.3 | 0.552 | 73 | 90.5 |
3379/3320 | 34.925 | 80.167 | 29.37 | 30.931 | 23.812 | 3.5 | 3.3 | 0.7 | 95 | 112 |
3490/3420 | 38.1 | 79.375 | 29.37 | 29.771 | 23.812 | 3.5 | 3.3 | 0.669 | 93 | 114 |
3767/3720 | 52.388 | 93.264 | 30.162 | 30.302 | 23.812 | 2.3 | 3.3 | 0.828 | 102 | 134 |
3780/3720 | 50.8 | 93.264 | 30.162 | 30.302 | 23.812 | 3.5 | 3.3 | 0.858 | 102 | 134 |
3872/3820 | 34.925 | 85.725 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 0.89 | 105 | 132 |
3876/3820 | 38.1 | 85.725 | 30.162 | 30.162 | 23.812 | 3.5 | 3.3 | 0.848 | 105 | 132 |
3982/3920 | 63.5 | 112.712 | 30.162 | 30.048 | 23.812 | 3.5 | 3.3 | 1.2 | 119 | 174 |
3984/3920 | 66.675 | 112.712 | 30.162 | 30.048 | 23.812 | 3.5 | 3.3 | 1.12 | 119 | 174 |
368/362 | 50.8 | 90 | 20 | 22.225 | 15.875 | 1.5 | 2 | 0.514 | 76.5 | 90.5 |
368A/362A | 50.8 | 88.9 | 20.638 | 22.225 | 16.513 | 3.5 | 1.3 | 0.5 | 76.5 | 90.5 |
368/363 | 50.8 | 90 | 20 | 22.225 | 20 | 1.5 | 0.8 | 0.546 | 76.5 | 90.5 |
368/363A | 50.8 | 88.9 | 20.638 | 22.225 | 16.513 | 1.5 | 1.3 | 0.502 | 70 | 87.5 |
387/382 | 57.15 | 98.425 | 21 | 21.946 | 17.826 | 2.3 | 0.8 | 0.596 | 78 | 96.5 |
387S/382A | 57.15 | 96.838 | 21 | 21.946 | 15.875 | 0.8 | 0.8 | 0.559 | 78 | 96.5 |
387A/382A | 57.15 | 96.838 | 21 | 21.946 | 15.875 | 3.5 | 0.8 | 0.557 | 78 | 96.5 |
390/394A | 57.15 | 110 | 21.999 | 21.996 | 18.124 | 1.8 | 1.1 | 0.908 | 89.5 | 120 |
395/394A | 63.5 | 110 | 22 | 21.996 | 18.824 | 3.5 | 1.2 | 0.837 | 89.5 | 120 |
395A/394A | 66.675 | 110 | 22 | 21.996 | 18.824 | 0.8 | 1.2 | 0.785 | 89.5 | 120 |
399A/394A | 68.263 | 110 | 21.999 | 21.996 | 18.824 | 1.8 | 1.1 | 0.715 | 89.5 | 120 |
462/453X | 57.15 | 104.775 | 30.162 | 29.317 | 24.605 | 2.3 | 3.3 | 1.01 | 115 | 148 |
462A/453X | 57.15 | 104.775 | 30.162 | 29.317 | 24.605 | 2.3 | 3.3 | 1.01 | 115 | 148 |
462/453 | 57.15 | 107.95 | 27.795 | 29.317 | 27 | 2.3 | 0.8 | 1.128 | 115 | 148 |
482/472 | 69.85 | 120 | 29.795 | 29.007 | 24.237 | 3.5 | 2 | 1.3 | 128 | 177 |
484/472 | 70 | 120 | 29.796 | 29.007 | 24.237 | 2 | 2 | 1.3 | 128 | 177 |
527/522 | 44.45 | 101.6 | 34.925 | 36.068 | 26.988 | 2.5 | 2.3 | 1.37 | 135 | 165 |
528X/520X | 50 | 100 | 34.925 | 35.999 | 26.988 | 2.5 | 2.3 | 1.2 | 120.5 | 103.9 |
529/522 | 50.8 | 101.6 | 34.925 | 36.068 | 26.988 | 0.8 | 3.3 | 1.23 | 135 | 165 |
535/532A | 44.45 | 111.125 | 38.1 | 36.957 | 30.162 | 3.5 | 3.3 | 1.79 | 129 | 144 |
239A/532X | 53.975 | 107.95 | 36.521 | 36.957 | 28.575 | 5.5 | 3.3 | 1.427 | 141 | 177 |
-------------------------------------------------------------------------------------------------------------------------------------------------------------
